Description
Key Features
- FLAME-RETARDANT: Withstands temperatures from 0º to 221ºF (-18º to 105ºC).
- THICKER FOR HEAVY-DUTY USE: Ensures a smooth wrap while remaining conformable.
- PROTECTS IN EXTREME CONDITIONS: Suitable for indoor and outdoor use, offering electrical and UV protection.
- HIGHLY COMPATIBLE: Works with solid dielectric cable insulations, rubber and synthetic splicing compounds, and epoxy and polyurethane resins.
- RELIABLE AND RESISTANT: Resists abrasion, moisture, alkalis, acids, and corrosion.
- PERMANENT INSULATION: Suitable for low-voltage primary and secondary insulation, cable jacketing, mechanical protection, and padding.
- PRESSURE-SENSITIVE ADHESIVE: Rubber-resin adhesive and PVC backing provide excellent electrical and mechanical protection.
- INSTALL AND MAINTAIN: Ideal for electrical installation, maintenance, and wireless network infrastructure accessories.
Applications
- Primary insulation for all wire and cable splices rated up to 600 volts and 105ºC (221ºF).
- Protective jacketing for high-voltage cable splices and repairs.
- Durable harnessing of wires and cables.
- Protective covering for bus bar insulation.
- Suitable for harsh indoor, outdoor, high-vibration, and abrasive applications.
Product Specifications
- Adhesive Type: Rubber, Rubber Mastic
- Backing Material: PVC
- Elongation at Break: 250%
- Flame Retardant: Yes
- Insulation Resistance: > 10^6 megohms
- Operating Temperature: 0ºF to 221ºF (-18ºC to 105ºC)
- Color: Black
- Shelf Life: 5 Years
- Certifications: UL Listed, CSA Certified, RoHS 2011/65/EU Compliant, IEC 60454-3-1-7/F-PVC P/90, VDE Marks License
- Tensile Strength: 35 N/10mm
- Total Tape Thickness: 0.22 mm (8.5 mil)
- Voltage Rating: 600 V
Dimensions and Sizes
- Lengths: 36 yd, 44 ft, 66 ft (13.4 m, 20 m, 32.9 m)
- Widths: 0.75 in, 1 in, 1.5 in, 2 in (19 mm, 25 mm, 38 mm, 50 mm)
Advantages
- Exceptional performance in extreme temperatures.
- High elasticity for smooth application and long-lasting insulation.
- Provides superior mechanical protection in harsh environments.
- Long shelf life for extended usability.
Why Choose RCS-88 Heavy Duty Super Vinyl Electrical PVC Tape – 0.22mm (8.5 mil)?
RCS-88 Heavy Duty Super Vinyl Electrical PVC Tape – 0.22mm (8.5 mil) is the ultimate solution for demanding electrical applications. Its flame-retardant properties, high resistance to UV, moisture, and chemicals, and compatibility with modern dielectric and epoxy resins make it a versatile and durable choice for professionals.
