Description
Key Features
- Transparent Design – Allows for easy inspection without removing the wrap.
- Self-Adhering – Sticks to itself when wrapped in layers, forming a durable and compact covering.
- Moisture-Proof Protection – Ensures long-lasting insulation and resistance to environmental factors.
- Tear-Resistant and Flexible – Combines strength with adaptability to various applications.
- Non-Adhesive – Leaves no residue, simplifying removal and repositioning.
- Lightweight and Easy to Handle – Simplifies application for professionals and DIY use.
Technical Specifications
- Thickness: 0.08mm (3mil)
- Width: 100mm (custom lengths and widths available upon request)
- Material: Elastic vinyl
- Length: 30 meters (standard)
No. |
Test Item |
Typical Value |
| 1 | Color | Transparent |
| 2 | Thickness | 0.075mm |
| 3 | Tensile Strength | ≥15MPa |
| 4 | Elongation at Break | 180 % |
| 5 |
Right angle tear strength
|
≥45 kN/M |
| 6 | Heating loss rate/%
|
≤5% |
| 7 | Temperature impact resistance
|
≤20% |
Applications
- Wire Splice Protection – Encases and secures wire groups and splice bundles.
- Encapsulation – Acts as a pressure medium for urethane encapsulated splices.
- Wire Management – Organizes closures and separates binder groups for easier identification.
- Telecommunication – Protects pulp and pic-insulated pairs, maintaining clean and organized closures.
- Heat Shrink Applications – Ideal for in-line heat shrink joints.
Advantages
- Ease of Use – Quick application with no tools required.
- Compact Splices – Pulls down large splice bundles for space-saving installations.
- Reusable and Adjustable – Maintains flexibility for future adjustments or modifications.
Standard Dimension
- Normal Dimension: 100mm × 0.08mm × 30m
- Custom lengths and widths are available to meet specific requirements.
Storage and Shelf Life
- Store in a dry, cool environment away from direct sunlight.
- Recommended shelf life: 24 months from the date of manufacture.
